| Specifications: |
| Mode | T-307 |
| Application fibers | SM,MM,NZ-DS,EDF,Pigtail,Cable(rubber-insulated wire) |
| Average Splice Loss | 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) |
| Return Loss | ≥60dB |
| Cladding Diameter | 100-150um |
| Coating Diameter | 100-1000um |
| Applicable cable | FTTH Drop Cable |
| Cleave Length | 9-16mm(∮0.25mm) ,10-16mm(∮0.9mm) |
| Quick splicing time | 9 seconds |
| Quick heating time | 16 seconds |
| Splicing Program | 50 groups |
| Heating Program | 10 groups |
| Protection Sleeve Length | 40mm,45mm,60mm |
| Operating Language | Chinese, English, French, Portuguese, Spanish,Russian |
| Operating Conditions | -10~+50°C(operation temperature),0~95% RH(humidity), 0-5000m(altitude) |
| Power Supply | AC input | AC adaptor: 100~240V input voltage, 50/60Hz; |
| DC input | 12V, 5A output voltage(DC) |
| Battery | Inner lithium battery: 11.1V, 5200mAh, Up to 220 times splice and heat |
| Monitor | Dual cameras, 90︒bi-dirctional view ,4.3 inches high resolution colorful LCD display |
| Fiber Image Magnification | X or Y Separately 520 times or Simultaneously 200 times |
| Estimated Splice Loss | Available |
| Cleaving angle detection | Available |
| Automatic setting | camera | Available |
| Forward motor |
| Tension Test | 1.96~2.25N |
| Storage of Splice Result | 6,000 groups of latest splice results |
| Splicing Model | Auto & Manual & Full Auto & Stepping |
| Optical Fiber Fixture | 3-in-1 cutting fixture;Multipurpose 1+N fixture (for SC/LC/FC connector) |
| Terminal | USB for Memorizing and Updating, Mini-USB |
| Dimensions | 120(W)*120(D)*130(H)mm,Package:43*32.5*26.5cm |
| Weight | 1.22kg(without battery ) /1.47kg with battery |
